Aqua-Loc coolant hoses
coolant hose Systemgröße 1/4" Art.-Nr. 08425-70
product coolant hose ( 23 elements ) system size ¼" passage 6 mm length ca. 295 mm colour black flow capacity 15 l / min coolant pressure 2 - 4 bar material DELRIN 500 article number 08425-70 note coolant hoses can be adapted to length as required can be combined for example with - threaded nipple ⅛" thread ( art.-nr. 08425-17 )
- round-faced nozzle 1,5 mm nozzle opening ( art.-nr. 08425-14 )
- flat-faced nozzle 25 mm nozzle opening ( art.-nr. 08425-19 )
- ball valve ⅛" inner thread ( art.-nr. 08525-113 )
coolant hose Systemgröße 1/2" Art.-Nr. 08450-55
product coolant hose ( 14 elements ) system size ½" passage 12 mm length ca. 290 mm colour black flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08450-55 note coolant hoses can be adapted to length as required can be combined for example with - threaded nipple ½" thread ( art.-nr. 08450-18 )
- round-faced nozzle 9 mm nozzle opening ( art.-nr. 08450-15 )
- flat-faced nozzle 50 mm nozzle opening ( art.-nr. 08450-19 )
- ball valve ½" inner thread ( art.-nr. 08525-116 )
coolant hose Systemgröße 3/4" Art.-Nr. 08475-14
product coolant hose ( 13 elements ) system size ¾" passage 19 mm length ca. 310 mm colour black flow capacity 50 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08475-14 note coolant hoses can be adapted to length as required can be combined for example with - threaded nipple ¾" thread ( art.-nr. 08475-18 )
- round-faced nozzle 16 mm nozzle opening ( art.-nr. 08475-100 )
- flat-faced nozzle 75 mm nozzle opening ( art.-nr. 08475-148 )
Aqua-Loc threaded nipples ( BSPT - cone threads )
threaded nipple Systemgröße 1/4" Art.-Nr. 08425-17⅛" thread
product threaded nipple system size ¼" passage 6 mm thread ⅛" colour grey flow capacity 15 l / min coolant pressure 2 - 4 bar material DELRIN 500 article number 08425-17 note connects to the coolant outlet of the machine can be combined for example with - coolant hose ¼" ( art.-nr. 08425-70 )
threaded nipple Systemgröße 1/4" Art.-Nr. 08425-18¼" thread
product threaded nipple system size ¼" passage 6 mm thread ¼" colour grey flow capacity 15 l / min coolant pressure 2 - 4 bar material DELRIN 500 article number 08425-18 note connects to the coolant outlet of the machine can be combined for example with - coolant hose ¼" ( art.-nr. 08425-70 )
threaded nipple Systemgröße 1/2" Art.-Nr. 08450-17⅜" thread
product threaded nipple system size ½" passage 12 mm thread ⅜" colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08450-17 note connects with the coolant outlet of the machine can be combined for example with - coolant hose ½" ( art.-nr. 08450-55 )
threaded nipple Systemgröße 1/2" Art.-Nr. 08450-18½" thread
product threaded nipple system size ½" passage 12 mm thread ½" colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08450-18 note connects with the coolant outlet of the machine can be combined for example with - coolant hose ½" ( art.-nr. 08450-55 )
threaded nipple Systemgröße 3/4" Art.-Nr. 08475-18¾" thread
product threaded nipple system size ¾" passage 19 mm thread ¾" colour grey flow capacity 50 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08475-18 note connects with the coolant outlet of the machine can be combined for example with - coolant hose ¾" ( art.-nr. 08475-14 )
Aqua-Loc threaded sockets ( BSPT - cone threads )
threaded socket Systemgröße 1/4" Art.-Nr. 08525-203⅛" thread
product threaded socket system size ¼" passage 6 mm thread ⅛" colour grey flow capacity 15 l / min coolant pressure 2 - 4 bar material DELRIN 500 article number 08525-203 note connects with the front end of the coolant hose can be combined for example with - coolant hose ¼" ( art.-nr. 08425-70 )
threaded socket Systemgröße 1/4" Art.-Nr. 08525-204¼" thread
product threaded socket system size ¼" passage 6 mm thread ¼" colour grey flow capacity 15 l / min coolant pressure 2 - 4 bar material DELRIN 500 article number 08525-204 note connects with the front end of the coolant hose can be combined for example with - coolant hose ¼" ( art.-nr. 08425-70 )
threaded socket Systemgröße 1/2" Art.-Nr. 08550-204⅜" thread
product threaded socket system size ½" passage 12 mm thread ⅜" colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08550-204 note connects with the front end of the coolant hose can be combined for example with - coolant hose ½" ( art.-nr. 08450-55 )
threaded socket Systemgröße 1/2" Art.-Nr. 08550-205½" thread
product threaded socket system size ½" passage 12 mm thread ½" colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08550-205 note connects with the front end of the coolant hose can be combined for example with - coolant hose ½" ( art.-nr. 08450-55 )
threaded socket Systemgröße 3/4" Art.-Nr. 08475-212¾" thread
product threaded socket system size ¾" passage 19 mm thread ¾" colour grey flow capacity 50 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08475-212 note connects with the front end of the coolant hose can be combined for example with - coolant hose ¾" ( art.-nr. 08475-14 )
Aqua-Loc nozzles
round-faced nozzle Systemgröße 1/4" Art.-Nr. 08425-141,5 mm
product round-faced nozzle system size ¼" passage 6 mm nozzle opening 1,5 mm colour orange flow capacity 15 l / min coolant pressure 2 - 4 bar material polypropylene article number 08425-14 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ¼" ( art.-nr. 08425-70 )
round-faced nozzle Systemgröße 1/4" Art.-Nr. 08425-153 mm
product round-faced nozzle system size ¼" passage 6 mm nozzle opening 3 mm colour orange flow capacity 15 l / min coolant pressure 2 - 4 bar material polypropylene article number 08425-15 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ¼" ( art.-nr. 08425-70 )
round-faced nozzle Systemgröße 1/4" Art.-Nr. 08425-166 mm
product round-faced nozzle system size ¼" passage 6 mm nozzle opening 6 mm colour orange flow capacity 15 l / min coolant pressure 2 - 4 bar material polypropylene article number 08425-16 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ¼" ( art.-nr. 08425-70 )
flat-faced nozzle Systemgröße 1/4" Art.-Nr. 08425-1925 mm ( slit )
product flat-faced nozzle system size ¼" passage 6 mm nozzle opening 25 mm ( slit ) colour orange flow capacity 15 l / min coolant pressure 2 - 4 bar material polypropylene article number 08425-19 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ¼" ( art.-nr. 08425-70 )
round-faced nozzle Systemgröße 1/2" Art.-Nr. 08450-146 mm
product round-faced nozzle system size ½" passage 12 mm nozzle opening 6 mm colour orange flow capacity 30 l / min coolant pressure 1 - 2 bar material polypropylene article number 08450-14 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ½" ( art.-nr. 08450-55 )
round-faced nozzle Systemgröße 1/2" Art.-Nr. 08450-159 mm
product round-faced nozzle system size ½" passage 12 mm nozzle opening 9 mm colour orange flow capacity 30 l / min coolant pressure 1 - 2 bar material polypropylene article number 08450-15 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ½" ( art.-nr. 08450-55 )
round-faced nozzle Systemgröße 1/2" Art.-Nr. 08450-1612 mm
product round-faced nozzle system size ½" passage 12 mm nozzle opening 12 mm colour orange flow capacity 30 l / min coolant pressure 1 - 2 bar material polypropylene article number 08450-16 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ½" ( art.-nr. 08450-55 )
flat-faced nozzle Systemgröße 1/2" Art.-Nr. 08450-1950 mm ( slit )
product flat-faced nozzle system size ½" passage 12 mm nozzle opening 50 mm ( slit ) colour orange flow capacity 30 l / min coolant pressure 1 - 2 bar material polypropylene article number 08450-19 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ½" ( art.-nr. 08450-55 )
round-faced nozzle Systemgröße 3/4" Art.-Nr. 08475-10016 mm
product round-faced nozzle system size ¾" passage 19 mm nozzle opening 16 mm colour orange flow capacity 50 l / min coolant pressure 1 - 2 bar material polypropylene article number 08475-100 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ¾" ( art.-nr. 08475-14 )
flat-faced nozzle Systemgröße 3/4" Art.-Nr. 08475-14875 mm ( slit )
product flat-faced nozzle system size ¾" passage 19 mm nozzle opening 75 mm ( slit ) colour orange flow capacity 50 l / min coolant pressure 1 - 2 bar material polypropylene article number 08475-148 note for pin-point directing of cutting fluids can be combinded for example with - coolant hose ¾" ( art.-nr. 08475-14 )
Aqua-Loc angular nozzles 90°
angular nozzle 90° Systemgröße 1/4" Art.-Nr. 08425-85
product angular nozzle 90° system size ¼" passage 6 mm nozzle opening 6 mm colour grey flow capacity 15 l / min coolant pressure 2 - 4 bar material polypropylene article number 08425-85 note for pin-point directing of cutting fluids towards hard-to-reach spots can be combined for example with - coolant hose ¼" ( art.-nr. 08425-70 )
multi-hole angular nozzle 90° Systemgröße 1/4" Art.-Nr. 08425-87
product multi-hole angular nozzle 90° system size ¼" passage 6 mm nozzle opening 6 x 1,5 mm colour grey flow capacity 15 l / min coolant pressure 2 - 4 bar material polypropylene article number 08425-87 note for pin-point directing of cutting fluids towards hard-to-reach spots, distributed via multiple fine nozzle openings
can be combined for example with - coolant hose ¼" ( art.-nr. 08425-70 )
angular nozzle 90° Systemgröße 1/2" Art.-Nr. 08450-98
product angular nozzle 90° system size ½" passage 12 mm nozzle opening 6 mm colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material polypropylene article number 08450-98 note for pin-point directing of cutting fluids towards hard-to-reach spots can be combined for example with - coolant hose ½" ( art.-nr. 08450-55 )
multi-hole angular nozzle 90° Systemgröße 1/2" Art.-Nr. 08450-02
product multi-hole angular nozzle 90° system size ½" passage 12 mm nozzle opening 7 x 3 mm colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material polypropylene article number 08450-02 note for pin-point directing of cutting fluids towards hard-to-reach spots, distributed via multiple fine nozzle openings can be combined for example with - coolant hose ½" ( art.-nr. 08450-55 )
angular nozzle 90° Systemgröße 3/4" Art.-Nr. 08475-139
product angular nozzle 90° system size ¾" passage 19 mm nozzle opening 15 mm colour grey flow capacity 50 l / min coolant pressure 1 - 2 bar material polypropylene article number 08475-139 note for pin-point directing of cutting fluids towards hard-to-reach spots can be combined for example with - coolant hose ¾" ( art.-nr. 08475-14 )
multi-hole angular nozzle 90° Systemgröße 3/4" Art.-Nr. 08475-141
product multi-hole angular nozzle 90° system size ¾" passage 19 mm nozzle opening 6 x 5 mm colour grey flow capacity 50 l / min coolant pressure 1 - 2 bar material polypropylene article number 08475-141 note for pin-point directing of cutting fluids towards hard-to-reach spots, distributed via multiple fine nozzle openings can be combined for example with - coolant hose ¾" ( art.-nr. 08475-14 )
Aqua-Loc y-shaped branching elements
y-shaped branching element Systemgröße 1/4" Art.-Nr. 08525-10
product y-shaped branching element system size ¼" passage 6 mm from > to 1 x ¼" > 2 x ¼" colour grey flow capacity 15 l / min coolant pressure 2 - 4 bar material DELRIN 500 article number 08525-10 note for branching and doubling of the coolant exit points
can be combined for example with - threaded nipple ⅛" thread ( art.-nr. 08425-17 )
- threaded nipple ¼" thread ( art.-nr. 08425-18 )
- coolant hose ¼" ( art.-nr. 08425-70 )
y-shaped branching element Systemgröße 1/2" Art.-Nr. 08550-10
product y-shaped branching element system size ½" passage 12 mm from > to 1 x ½" > 2 x ½" colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08550-10 note for branching and doubling of the coolant exit points
can be combined for example with - threaded nipple ⅜" thread ( art.-nr. 08450-17 )
- threaded nipple ½" thread ( art.-nr. 08450-18 )
- coolant hose ½" ( art.-nr. 08450-55 )
y-shaped branching element Systemgröße 3/4" Art.-Nr. 08575-10
product y-shaped branching element system size ¾" passage 19 mm from > to 1 x ¾" > 2 x ¾" colour grey flow capacity 50 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08575-10 note for branching and doubling of the coolant exit points
can be combined for example with - threaded nipple ¾" thread ( art.-nr. 08475-18 )
- coolant hose ¾" ( art.-nr. 08475-14 )
Aqua-Loc reduction elements
reduction element Systemgröße 1/2" Art.-Nr. 08450-20
product reduction element system size ½" passage 12 mm from > to ½" > ¼" colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08450-20 note for reduction of the system size can be combined for example with - threaded nipple ⅜" thread ( art.-nr. 08450-17 )
- threaded nipple ½" thread ( art.-nr. 08450-18 )
- coolant hose ½" ( art.-nr. 08450-55 )
- coolant hose ¼" ( art.-nr. 08425-70 )
reduction element Systemgröße 3/4" Art.-Nr. 08475-20
product reduction element system size ¾" passage 19 mm from > to ¾" > ½" colour grey flow capacity 50 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08475-20 note for reduction of the system size can be combined for example with - threaded nipple ¾" thread ( art.-nr. 08475-18 )
- coolant hose ¾" ( art.-nr. 08475-14 )
- coolant hose ½" ( art.-nr. 08450-55 )
Aqua-Loc y-shaped reduction element
y-shaped reduction element Systemgröße 1/2" Art.-Nr. 08550-13
produkt y-shaped reduction element system size ½" passage 12 mm from > to 1 x ½" > 2 x ¼" colour grey flow capacity 30 l / min coolant pressure 1 - 2 bar material DELRIN 500 article number 08550-13 note for branching and doubling of the coolant exit points and reduction of the system size
can be combinde for example with - threaded nipple ⅜" thread ( art.-nr. 08450-17 )
- threaded nipple ½" thread ( art.-nr. 08450-18 )
- coolant hose ½" ( art.-nr. 08450-55 )
- coolant hose ¼" ( art.-nr. 08425-70 )
Aqua-Loc ball valves with inner thread
ball valve Systemgröße 1/4" Art.-Nr. 08525-113⅛" inner thread
product ball valve system size ¼" passage 6 mm inner thread ⅛" colour metallic / black flow capacity 15 l / min coolant pressure 2 - 4 bar material zinc-coated metal / plastics ( handle ) article number 08525-113 note for regulation of the flow capacity or switching off of individual system parts
can be combined for example with - threaded socket ⅛" ( art.-nr. 08525-203 )
- threaded nipple ⅛" ( art.-nr. 08425-17 )
ball valve Systemgröße 1/4" Art.-Nr. 08525-114¼" inner thread
product ball valve system size ¼" passage 6 mm inner thread ¼" colour metallic / black flow capacity 15 l / min coolant pressure 2 - 4 bar material zinc-coated metal / plastics ( handle ) article number 08525-114 note for regulation of the flow capacity or switching off of individual system parts can be combined for example with - threaded socket ¼" ( art.-nr. 08525-204 )
- threaded nipple ¼" ( art.-nr. 08425-18 )
ball valve Systemgröße 1/2" Art.-Nr. 08525-115⅜" inner thread
product ball valve system size ½" passage 12 mm inner thread ⅜" colour metallic / black flow capacity 30 l / min coolant pressure 1 - 2 bar material zinc-coated metal / plastics ( handle ) article number 08525-115 note for regulation of the flow capacity or switching off of individual system parts can be combined for example with - threaded socket ⅜" ( art.-nr. 08550-204 )
- threaded nipple ⅜" ( art.-nr. 08450-17 )
ball valve Systemgröße 1/2" Art.-Nr. 08525-116½" inner thread
product ball valve system size ½" passage 12 mm inner thread ½" colour metallic / red flow capacity 30 l / min coolant pressure 1 - 2 bar material zinc-coated metal / plastics ( handle ) article number 08525-116 note for regulation of the flow capacity or switching off of individual system parts can be combined for example with - threaded socket ½" ( art.-nr. 08550-205 )
- threaded nipple ½" ( art.-nr. 08450-18 )
Aqua-Loc assembly pliers
assembly plier Systemgröße 1/4" Art.-Nr. 08425-90
product assembly plier for system size ¼" colour black material long fiber nylon article number 08425-90 note for convenient assembly of all ¼" components
assembly plier Systemgröße 1/2" Art.-Nr. 08450-90
product assembly plier for system size ½" colour black material long fiber nylon article number 08450-90 note for convenient assembly of all ½" components
Aqua-Loc Opti-arm
Opti-arm Systemgröße 1/2" Art.-Nr. 08550-50
product Opti-arm for system size ½" colour black materials DELRIN 500 ( hose ), plastics ( clamp ) article number 08550-50 note with powerful holding clamp and strong magnetic base
Aqua-Loc Opti-shields
Opti-shield small Systemgröße 1/2" Art.-Nr. 08550-26
product Opti-shield small for system size ½" colours black / transparent materials DELRIN 500 ( hose ), polycarbonate ( shield ) shield size 150 x 150 mm article number 08550-26 note with coolant hose of system size ½", strong magnetic base and 360 ° adjustable transparent protective shield
Opti-replacement-shield small Systemgröße 1/2" Art.-Nr. 08550-56
product Opti-replacement-shield small for system size ½" colours black / transparent materials DELRIN 500 ( holder ), polycarbonate ( protective shield ) shield size 150 x 150 mm article number 08550-56 note suitable for 08550-26
Opti-shield medium size Systemgröße 1/2" Art.-Nr. 08550-75
product Opti-shield medium size for system size ½" colours black / transparent materials DELRIN 500 ( hose ), polycarbonate ( shield ) shield size 225 x 225 mm article number 08550-75 note with coolant hose of system size ½", strong magnetic base and 360 ° adjustable transparent protective shield
Opti-replacement-shield medium size Systemgröße 1/2" Art.-Nr. 08550-79
product Opti-replacement-shield medium size for system size ½" colours black / transparent materials DELRIN 500 ( holder ), polycarbonate ( protective shield ) shield size 225 x 225 mm article number 08550-79 note suitable for 08550-75
Opti-shield large Systemgröße 1/2" Art.-Nr. 08550-55
product Opti-shield large for system size ½" colours black / transparent materials DELRIN 500 ( hose ), polycarbonate ( shield ) shield size 300 x 300 mm article number 08550-55 note with coolant hose of system size ½", strong magnetic base and 360 ° adjustable transparent protective shield
Opti-replacement-shield large Systemgröße 1/2" Art.-Nr. 08550-59
product Opti-replacement-shield large for system size ½" colours black / transparent materials DELRIN 500 ( holder ), polycarbonate ( protective shield ) shield size 300 x 300 mm article number 08550-59 note suitable for 08550-55
